Speroni Surface Pumps
V8
Application
In-line mult-stage centrifugal pumps for domestic or municipal water supply systems, for clean non-explosive liquids without solid or abrasive substances, for agricultural irrigation and sports application, for civil and industrial use, boiler feeding and condensate systems and for high pressure washing plants.
Operating Conditions
- Liquid temperature up to 35°C (for home use according to EN 60335-2-41)
- Temperature max. liquid: 110°C (for other uses)
- Ambient temperature max to 40°C
MOTOR
- Two-pole electric standard motor (n = 2900 min-1)
- Insulation Class F
- Protection IP 55
MATERIALS
- Suction Casing Stainless Steel AISI 304
- Delivery Casing Stainless Steel AISI 304
- Impeller Stainless Steel AISI 304
- External Jacket Stainless Steel AISI 304
- Upper Cover Stainless Steel AISI 304
- Lower Cover Stainless Steel AISI 304
- Pump shaft Stainless Steel AISI 304
- Mechanical seal Silicon/Silicon/Viton
